Description
| Technical Specification | Details |
|---|---|
| Ambient Air Temperature – Operation | -25 … +70 °C |
| Ambient Air Temperature – Storage | -40 … +85 °C |
| Color | Yellow |
| Actuator Type | Pilot light head |
| Illumination | Illuminated |
| Lamp Type | 24V AC / DC, integrated LED |
| Enclosure Type NEMA | Type1, Type12, Type13, Type3R, Type4, Type4X |
| Pollution Degree | 3 |
| Rated Frequency (f) | Supply Circuit 50 / 60 Hz |
| Rated Operational Voltage | 24 V AC/DC |
| Connecting Capacity | Flexible with Ferrule: 1 x 0.75…2.5 mm², 2 x 0.75…2.5 mm² Flexible with Insulated Ferrule: 1 x 0.75…2.5 mm², 2 x 0.75…2.5 mm² Flexible: 1 x 0.75…2.5 mm², 2 x 0.75…2.5 mm² Solid: 1 x 0.75…2.5 mm², 2 x 0.75…2.5 mm² |
| Connection Type | Screw Clamp |
| Terminal Type | Screw Terminals |
| Tightening Torque | 0.9 N·m |
| Wire Stripping Length | 8 mm |
