Description
| Technical | Details |
|---|---|
| Ambient Air Temperature | Operation: -25 … +70 \u00b0C Storage: -40 … +85 \u00b0C |
| Color | Blue |
| Actuator Type | Pilot light head |
| Illumination | Illuminated |
| Lamp Type | 230 V AC, integrated LED |
| Enclosure Type NEMA | Type 1, Type 12, Type 13, Type 3R, Type 4, Type 4X |
| Pollution Degree | 3 |
| Rated Frequency (f) | Supply Circuit 50 / 60 Hz |
| Rated Operational Voltage | 230 V AC |
| Connecting Capacity | Flexible with Ferrule 1 x 0.75…2.5 mm\u00b2 Flexible with Ferrule 2 x 0.75…2.5 mm\u00b2 Flexible with Insulated Ferrule 1 x 0.75…2.5 mm\u00b2 Flexible with Insulated Ferrule 2 x 0.75…2.5 mm\u00b2 Flexible 1 x 0.75 … 2.5 mm\u00b2 Flexible 2 x 0.75 … 2.5 mm\u00b2 Solid 1 x 0.75…2.5 mm\u00b2 Solid 2 x 0.75…2.5 mm\u00b2 |
| Connection Type | Screw Clamp |
| Terminal Type | Screw Terminals |
| Tightening Torque | 0.9 N\u00b7m |
| Wire Stripping Length | 8 mm |
