Description
| Technical | Details |
|---|---|
| Terminal Type | Screw Terminals |
| Rated Operational Voltage | 690 V AC 600 V DC Main Circuit 690 V |
| Rated Operational Current AC-15 (Ie) | (24 V) 6 A (240 V) 4 A (690 V) 1 A (380 / 400 V) 3 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 2 A (125 V) 0.55 A (250 V) 0.27 A (440 V) 0.15 A (600 V) 0.15 A |
| Rated Impulse Withstand Voltage (Uimp) | Auxiliary Circuit 6 kV |
| Rated Insulation Voltage (Ui) | 690 V |
| Degree of Protection | IP20 |
| Electrical Durability | 100,000 cycles |
| Mechanical Durability | 100,000 cycles |
| Connecting Capacity Auxiliary Circuit | Flexible with Ferrule: 1/2x 0.75 … 1.5 mm² Flexible with Insulated Ferrule: 1/2x 0.75 … 1.5 mm² Flexible: 1/2x 0.75 … 1.5 mm² Rigid: 1/2x 1 … 1.5 mm² |
| Tightening Torque | Auxiliary Circuit: 0.8 … 1.2 N·m |
| Wire Stripping Length | Auxiliary Circuit: 8 mm |
| Recommended Screw Driver | M3 Pozidriv 2 |
| Number of Auxiliary Contacts | NO: 1 NC: 1 CO (SPDT): 0 |
| Product Name | Auxiliary Contact |
| Suitable For | MS116, MS132, MO132, MS165, MO165 |
| Suitable for Product Class | Manual Motor Starter |
| Accessory Group | Electrical |
| Accessory Type | Auxiliary Contact |
