Description
| Specification | Details |
|---|---|
| ABB EcoSolutions | Yes |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops – Standard EN45555 – 91.69 % |
| ABB Site Meeting Group Waste To Landfill Target | No non-hazardous waste is sent to a landfill |
| Sustainable Material Content in Packaging (wt. %) | FSC 100% Paper – 43.11 % FSC 100% Paper – 30.23 % FSC Mix Paper – 23.68 % 0 % 0 % |
| Extended Product Lifetime | Product Durability |
| End Of Life Disassembling Instructions | SB200M, SB200DC End of Life Instruction |
| Environmental Product Declaration – EPD | EPD SB200M MCB 10kA |
| Rated Operational Current (Ie) | 50 A |
| Rated Service Short-Circuit Breaking Capacity (Ics) | 7.5 kA |
| Energy Limiting Class | 3 |
| Electrical Endurance | 10000 AC cycle |
| Mechanical Endurance | 20000 cycle |
| Number of Protected Poles | 4 |
| Number of Poles | 4P |
| Tightening Torque | 2 N·m |
| Actuator Type | Toggle |
| Screw Terminal Type | Cage Terminal |
| Actuator Marking | I / O |
| Actuator Material | Insulation Group II, Black, Sealable |
| Recommended Screw Driver | Pozidriv 2 |
| Accessories Available | Yes |
| Remarks | IP40 in enclosure with cover |
| Connecting Capacity | rigid: 25 mm²; flexible: 16 mm² |
| Tripping Characteristic | C |
| Rated Voltage (Ur) | 415 V |
| Operational Voltage | Max 264 V AC / Max 60 V DC |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| Rated Current (In) | 50 A |
| Rated Short-Circuit Capacity | 10 kA |
| Rated Frequency (f) | 50 Hz |
| Overvoltage Category | III |
| Housing Material | Insulation Group II, RAL 7035 |
| RoHS Information | 1SYM100001D1015 |
| RoHS Status | Following EU Directive 2011/65/EU |
| RoHS Date | 43546 |
| Conflict Minerals Reporting Template | Conflict Minerals Reporting Template |
| WEEE Category | Product Not in WEEE Scope |
| Ambient Air Temperature | -25 … +55 °C |
| Reference Ambient Air Temperature | 30 °C |
| Degree of Protection | IP20 |
| Pollution Degree | 2 |
| Environmental Conditions | 28 cycle 55°C @ 90-96% 25°C @ 95-100% |
| Resistance to Vibrations | 20 Cycles with Load 0.8 In: 5g 5–150 Hz 20 Cycles with Load 0.8 In: 6g 35 Hz |
| Resistance to Shock acc. to IEC 60068-2-27 | 25g / 2 shock / 13 ms |
