| Technical | Details |
|---|---|
| Cable Cross-Section | 2.5 ... 16 mm² |
| Conventional Free-air Thermal Current (Ith) | Θ = 40 °C 45 A |
| Conventional Thermal Current (Ithe) | Fully Enclosed 45 A |
| Degree of Protection | Front IP20 |
| Handle Color | Black |
| Handle Type | Knob handle |
| Mounting Type | Base mounting, DIN-rail mounting |
| Number of Circuits | 1 |
| Number of Poles | 3P |
| Operating Mode | Front Operated |
| Pollution Degree | 3 |
| Position of Line Terminals | Top In - Bottom Out, Bottom In - Top Out |
| Positive Opening Operation Torque | 0.4 … 0.8 N·m |
| Power Loss | 0.5 W per pole |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Current DC-21B (Ie) | 600 V: 36 A, 1000 V: 32 A |
| Rated Operational Voltage | 1000 V |
| Rated Short-Circuit Making Capacity (Icm) | 1000 V DC: 0.8 kA |
| Rated Short-time Withstand Current Low Voltage (Icw) | 1000 V DC: 0.8 kA for 1 s |
| Recommended Screw Driver | Main Circuit Torx |
| Shaft Diameter | 6 mm / 0.24 in |
| Special Functions | No |
| Standards | IEC 60947-1, -3 |
