Description
| Electrical Data | |
|---|---|
| Amperage Rating | 125 A |
| Voltage Rating | 280 V |
| Rated Voltage AC | 280 V |
| Rated Voltage DC | 150 V |
| Interrupt Rating | 200 kAIC |
| 200 kA RMS Sym, 50 kA DC at 150 VDC | |
| Class | Class aR |
| Pre Arc (IΒ²T) | 600 |
| Clearing (IΒ²T) | 7500 |
| Watt Losses | 16 W |
| Product Specifications | |
| Application | Semiconductor, DC Common Bus, DC Drives, Power Converters/Rectifiers |
| Fuse Indicator | None |
| Compatible Trip Indicator / Microswitch | |
| Suitable For | TI500 Fuse Indicator |
| MAI Microswitch/Adaptor | |
| MBI Microswitch/Adaptor |
