Selecting the right fuse can be challenging, especially when considering the Eaton Bussmann Series High-Speed Square Body Fuse 170M3817D. If you’re wondering about its technical specifications or performance in various applications, we’re here to help. To make your decision easier, we’ve gathered all the essential details, including its key features, specifications, and benefits.
FAQ: Eaton Bussmann Series 170M3817D High-Speed Fuse
The Eaton Bussmann Series 170M3817D is a high-speed, square body fuse designed for reliable protection in high-power electrical circuits. It’s specifically engineered to protect sensitive electrical components from overloads and short circuits, particularly in demanding industrial applications like semiconductor protection, DC common bus systems, DC drives, and power converters/rectifiers.
This fuse is rated at 700V (UL) and 690V (IEC), with a current rating of 315A. This makes it suitable for a wide range of industrial applications requiring these voltage and amperage levels.
The Eaton Bussmann 170M3817D fuse has a high interrupting capacity of 200 kAIC (kiloampere interrupting capacity). This means it can safely interrupt fault currents up to 200,000 amps, providing robust protection for electrical circuits.
The Eaton Bussmann 170M3817D is a Class aR fuse. This classification indicates that it is specifically designed for “Accompanied Semiconductor Protection,” meaning it is very fast-acting and ideally suited for protecting sensitive semiconductors and power electronics from damage due to overcurrent conditions.
The fuse uses a DIN 43-620 blade end connection. This ensures a secure and reliable installation, as well as facilitates easy replacement of the fuse when necessary.
Yes, the Eaton Bussmann 170M3817D features a combination fuse status indicator. This allows for quick and easy identification of the fuse’s condition (whether it is still functioning or has blown).
The Eaton Bussmann Series Fuse 170M3817D can be purchased from Shansen Enterprises, an authorized channel partner for Eaton Bussmann fuses. Shansen Enterprises serves various regions in India, offering ready stock and on-time delivery.
The fuse has the following dimensions: Product Length/Depth: 135 mm, Product Height: 64 mm, and Product Width: 40 mm. The product weight is approximately 422.83 grams.
Eaton Bussmann 170M3817D Fuse: High-Speed Protection for Industrial Applications ⚡
Shansen Enterprises promotes the Eaton Bussmann Series 170M3817D high-speed square body fuse. This fuse provides reliable, fast-acting protection for high-power industrial applications, operating at 700V (UL) / 690V (IEC) with a 315A rating and a 200kAIC interrupting capacity. Key features include a combination fuse status indicator and DIN 43-620 blade end connections. The fuse is suitable for protecting semiconductors and power electronics with its Class aR rating. Shansen Enterprises, an authorized Eaton Bussmann partner, offers this product with fast shipping across India.
