Description
Technical Standards: | IEC 61008; IS12640-1:2008 |
Type of Residual Current: | Type AC |
Rated Operational Voltage: | 240 V AC |
Rated Insulation Voltage (Ui): | 500 V |
Rated Impulse Withstand Voltage (Uimp): | 4 kV |
Dielectric Test Voltage: | 2.5 kV |
Rated Current (In): | 25 A |
Rated Residual Current: | 30 mA |
Rated Conditional Short-Circuit Current (Inc): | 10 kA |
Rated Frequency (f): | 50 Hz |
Electrical Endurance: | 10000DC cycle |
Mechanical Endurance: | 20000 cycle |
Number of Poles: | 2 |
Tightening Torque: | 2.8 N·m |
Actuator Type: | Toggle |
Actuator Marking: | I / O |
Recommended Screw Driver: | Pozidriv 2 |
Remarks: | Protection degree terminals: IP20; with housing IP40 |
