Eaton PLSI C40/2-GI Miniature Circuit Breaker

Eaton PLSI-C40/2-GI Miniature Circuit Breaker | 40A Double Pole | C-Curve | 10kA | ISI & CE Certified

Looking for a compact, rugged, and reliable circuit breaker for your 240/415 V installations? The Eaton PLSI-C40/2-GI (EIN-810154) MCB combines global-standard protection with features designed specifically for Indian electrical environments. With dual-pole switching, a C-curve tripping profile, and a high 10kA short-circuit capacity, this breaker is ideal for a wide range of residential, commercial, and light industrial applications. Fully compliant with IS/IEC 60898-1 and EN/IEC 60898-1, and certified with ISI and CE marks.

Key Features at a Glance

• ✅ Rated current: 40A, C-curve tripping (5–10×In)

• ✅ Voltage rating: 240/415 V AC, 50Hz

• ✅ 10kA short-circuit capacity for enhanced safety

• ✅ Trip-free mechanism ensures reliable disconnection

• ✅ Red/green contact position indicator for clear status

• ✅ Anti-weld silver alloy contacts with 13-plate arc chute

• ✅ Energy limiting Class 3 for minimal let-through energy

• ✅ IP20 housing with flame-retardant body

• ✅ Mechanical life: 10,000 operations

• ✅ Bi-connect terminals for flex up to 16 mm² and rigid up to 25 mm²

• ✅ DIN-rail mounting (35mm) with 2-position clip

• ✅ Compact: Only 35mm wide (2×17.5mm modules)

Why Choose This Product

The Eaton PLSI-C40/2-GI is engineered for dependable circuit protection with fast-acting thermal-magnetic trip technology. Its high interrupt rating, trip-free mechanism, and compact footprint make it a reliable choice for modern power distribution boards. Whether you’re upgrading an existing setup or working on a fresh install, this MCB ensures both operational safety and peace of mind with minimal maintenance.

Ideal For:

• Residential electrical panels

• Commercial office circuits

• Shops and small businesses

• Light industrial facilities

• Utility boards and distribution boxes

Request a WhatsApp Quote

Shansen Enterprises is a trusted Authorized Channel Partner of Eaton. We ensure 100% genuine products with verified datasheets and prompt support. To get the best price on the PLSI-C40/2-GI, just message us on WhatsApp—we’re always happy to help!
