Description
Specifications
| Electrical | |
| Connection type | 3-phase 4-wire, direct connected |
| Rated voltage | 230/240 V |
| Impulse withstand | 10 kV, 2 β¦ setup |
| Current range | 5-30 A/10-60 A/10-100 A |
| Frequency | 50 Hz, Β± 5% |
| Accuracy class | Class 1.0 |
| Metrology lamp | Two metrological LEDs for active and reactive energy |
| Burden | |
| Voltage circuit | 0.32 W/0.6 VA per phase |
| Current circuit | <0.1 VA |
| Compliance | |
| Standards | IS 13779, IS15959 for ICS and CBIP 325 for magnet |
| Mechanical | |
| Dimensions (W x H x D) | 126 mm x 222 mm x 92 mm |
| Meter case: | LEXAN 143/ 943 or equivalent |
| Terminal block: | LEXAN 500R/equivalent |
| Weight: | 0.78 kg (approx.) |
| Sealing provision | One wire seal and one paper seal between body and terminal block, two on terminal block cover |
