Description
| Technical Details | Specifications |
|---|---|
| Terminal Type | Screw Terminals |
| Rated Operational Voltage | 250 V |
| Rated Operational Current AC-15 (Ie) | (24 V) 3 A (120 V) 3 A (240 V) 1.5 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 1 A (125 V) 0.27 A (250 V) 0.11 A |
| Rated Frequency (f) | Auxiliary Circuit DC Auxiliary Circuit 50 Hz Auxiliary Circuit 60 Hz |
| Rated Impulse Withstand Voltage (Uimp) | Auxiliary Circuit 6 kV |
| Rated Insulation Voltage (Ui) | 250 V |
| Degree of Protection | IP20 |
| Electrical Durability | 100000 cycle |
| Mechanical Durability | 100000 cycle |
| Connecting Capacity Auxiliary Circuit | Flexible with Ferrule 1/2x 0.75 … 1.5 mm² Flexible with Insulated Ferrule 1/2x 0.75 … 1.5 mm² Flexible 1/2x 0.75 … 1.5 mm² Rigid 1/2x 1.0 … 2.5 mm² |
| Tightening Torque | Auxiliary Circuit 0.8 … 1.2 N·m |
| Wire Stripping Length | Auxiliary Circuit 8 mm |
| Recommended Screw Driver | M3 Pozidriv 2 |
| Number of Auxiliary Contacts NO | 1 |
| Number of Auxiliary Contacts NC | 1 |
| Product Name | Auxiliary Contact |
| Suitable For | MS116 MS132 MO132 MS165 MO165 |
| Suitable for Product Class | Manual Motor Starter |
| Accessory Group | Electrical |
| Accessory Type | Auxiliary Contact |
