Description
Specification
Electrical | |
Connection type | Direct connected |
Wiring configuration | 3-phase 4-wire |
Voltage reference | 240/230 V (L-N) |
Voltage variation | -40% to +30% |
Current range | 10-100 A |
Accuracy | Class 1.0 |
Frequency | 50 Hz ±5%, 60 Hz ±5% |
Compliance | |
Standards | IS 13779, IS 15884, IS 15959 and IEC62055-31 |
Mechanical | |
Dimensions (W x H x D) | 184 mm x 207 mm x 98 mm (with extended terminal cover) |
Weight | 1.5 kg |
Enclosure | Engineering plastic |
Sealing | Sealed for life, additional sealing provision at meter cover and terminal cover |
Environmental | |
Ingress | protection IP 54 |
Temperature | -10 °C to +60 °C (operating) -25 °C to +70 °C (storage) |
Humidity | 95%, non-condensing |
